ZMC-CHSJ-ML-5  –  5 layers film blowing machine

  • Description


ZMC-CHSJ-ML-5  –  5 layers film blowing machine

Model □ML-5-50+55+65/1700
Film width (mm) □800-1500mm
Film thickness 0.03-0.20mm
max output


According to different width, the thickness of the film, die size and raw material characteristics to change
suitable material LDPE LLDPE HDPE EVA PP NYLON
Diameter of screw □Φ50*2,Φ55*2,Φ65*5*1 ,30/1

SACM 645, bimetallic ,five years guarantee

Main motor □22kw*2, 30kw*2 ,37kw*1
100% Original three-phase variable frequency motor  Equipped with inverter control
Take up roller(mm) □1700mm
Overall dimension(L*W*H)m   □14x10x12

Note: The above specifications, dimensions & design characteristics are subject to change without notice

Optional device:

Automatic Hopper Loader

Film Surface Treater

Rotary Die

Oscillating Take Up Unit

Two Stations Surface Winder


Heat Slitting Device

Gravimetric Dosing Unit

IBC (Internal Bubble Cooling Computer Control System)

EPC (Edge Position Control)

Electronic Tension Control

Manual mechanics screen changer

Edge material recycling machine
