ZMC-SCR-2-CH

ZMC-SCR-2-CH

Double line automatic 2 lines rolling bag making machine (with core)

  • Description

Description

Double line automatic 2 lines rolling bag making machine (with core)

Features

  • Computer control over the entire process
  • Servo motor, as standard attachment, makes it easy to adjust the bag length and the production speed
  • Automatic film feeding, coordination free from tension adjustment
  • Automatically stop when running out of the film
  • Automatically stop when film feeding blocks or bags jam
  • Automatically stop when color scanning misses
  • High production efficiency to save manpower and time
  • Automatically core changing

Specifications

MODEL SCR-40
POWER 220 V 3 Phases, 50/60 Hz, 18 kV
DRIVING MOTOR AC 1 HP x 1, AC 1/2 HP x 4, AC 1/3 HP x 4
HEATER 3.5 kW
BAG LENGTH 150 – 750 mm
BAG WIDTH 100 – 330 mm
BAG THICKNESS 8-35 µ
SPEED Max. 110 meter/min/track
MAX. DIA.OF ROLL Ø180 x W 330 mm
DIMENSIONS L x W x H 609 x 240 x 192 cm
MACHINE WEIGHT 3200 kgs
PACKING LxWxH Unwinder: 226 x 258 x 188 cm
Main Machine: 288 x 161 x 151 cm
GROSS WEIGHT 3500 kgs
AIR COMPRESSOR 6 HP (Not Included)
