ZMC-SSH-CH
This machine has four functions (soft loop handle bag, patch handle bag, poly draw handle
Bag, die cut handle bag). It is coupled with machinery, light, electronic and pneumatic
Enquiry about ZMC-SSH-CH
- Description
Description
PRODUCT INFORMATION
This machine has four functions (soft loop handle bag, patch handle bag, poly draw handle
Bag, die cut handle bag). It is coupled with machinery, light, electronic and pneumatic
Feature:
- Flexible soft loop handle and patch film feeding system, fully automatic
- Pre-sealing knife, heated on double sides and strong for fusing, to make the bags without deformation
- The best quality of Italian side sealing knife, Heated to high temperatures, not deformation
- Newly design of sealing knife top lift and turn over the system
5. It’s designed by heating punching and it’s easy to cut off, the waster is excluded automatically
Optional equipment:
① Single sheet film folding unit, hydraulic loading device (connector fission)
② Top folding continuously sealing device
③ Bottom seal knife + double seal knife
Technical parameter:
| Type | ZMC-SSH-800-CH | |
| Length of bag making (height of the bag) | 250-750mm | |
| Width of bag making | 250-600mm | |
| Top folded | 50-75mm | |
| Bottom insert | 20-70mm | |
| Speed of bag making | Soft loop handle bag | 60pcs/min |
| Patch handle bag | 60pcs/min | |
| Poly drawstrings bag | 65pcs /min | |
| Die cut bag | 80pcs /min | |
| Total power | 13KW | |
| Machine weight | 3500kg | |
| Machine dimension | 8200X3100X1870mm | |
| Air compressor (not included) | 6HP | |
* The specification is subject to be changed for an improvement without notice
