ZMC-CHSJ-PC series ABC PP film blowing machine

  • Description


ZMC-CHSJ-PC series ABC PP film blowing machine

Model PP-ABC-45/900 PP-ABC-55/1300
Film width (mm) 400-800mm 500-1200mm
Film thickness 0.006-0.08mm 0.006-0.08mm
 max output □75kg/h □100kg/h
According to different width, thickness of film, die size and raw material characteristics to change
suitable material PP/LDPE
Diameter of screw Φ45×3,30/1 Φ55×3,30/1
SACM 645 ,bimetallic ,five years guarantee
Main motor 15kw×3 22kw×3
100% Original three-phase variable frequency motor  Equipped with inverter control
Take up roller(mm)  900mm 1300mm
Weight 7500kg 12000kg

Note: the above specifications, dimensions & design characteristics are subject to change without notice

Optional device:

Automatic Hopper Loader

Film Surface Treater

Rotary Die

Oscillating Take Up Unit

Two Stations Surface Winder


Heat Slitting Device

Gravimetric Dosing Unit

IBC(Internal Bubble Cooling Computer Control System)

EPC(Edge Position Control)

Electronic Tension Control

Manual mechanics screen changer

Edge material recycling machine
